Sierra Flame INS-FM Electric Insert with Dual Steel Surround Fireplace

Add new life to an existing wood or masonry fireplace with Sierra Flame’s stylish Flush Mount INS-FM Electric Insert.

The stunning and life-like ‘gradient’ flame is intensified by the visually impressive traditional log set, included with your insert. Finished with a black steel surround, the versatile design of this insert will work with any décor style.

Conveniently control the flame height and intensity of the natural-looking flame with the included remote control.

Ideal for zone heating, this electric insert easily heats a space of 400 to 500 sq ft in size.

The INS-FM electric insert comes standard with a black overlay.

Included Accessories

• The INS-FM  comes with a  log set, a sable, and a remote.

Product Features

• Great alternative for wood or gas inserts
• Perfect for renovations or retrofits
• 2 popular sizes
• Heat is vented upwards
• Hardwire ready
• Stunning ‘Gradient’ Flame
• Black Steel surround
• No grills
• 4 stage front and 4 stages internal backlighting
• Latest LED light technology
• Front and rear control for flame and heater included
• Can produce up to 5000 BTU of heat, enough to heat up to 500 sq feet
• Plug on the left side
• Flame operates with or without heat
• Remote control for flame and heater
• 4 leveling legs on the underside

Product Information

30" Specifications

Volts	120
Amps	12.5
Watts	1500
Heater	High: 1500 Watts Low: 750 Watts
No Heater	19 watts
LED Lamps	22 Watts
Rotor Motor	1 at 5 watts
Dimensions (in.)	19 H x 29 3/8 W x 8 1/2 D
Glass Viewing Opening (in.)	15 3/8 x 23 1/12
Surround Size (in.)	24 7/8” x 38
Shipping Size (in.)	27 3/4 x 41 1/2 x 12 3/4
Shipping Weight (Glass Front Included)	64 lbs
Plug Location	Left Side
Cord Length	74”
Approx. Heating Area	400 sq ft



34" Specifications

Volts	120
Amps	12.5
Watts	1500
Heater	High: 1500 Watts Low: 750 Watts
No Heater	19 watts
LED Lamps	22 Watts
Rotor Motor	1 at 5 watts
Dimensions (in.)	23 1/8 H x 33 1/8 W x 8 1/2 D
Glass Viewing Opening (in.)	17 3/8 x 27 5/8
Surround Size (in.)	24 7/8” x 38
Shipping Size (in.)	32 3/4 x 45 1/8 x 12 3/4
Shipping Weight (Glass Front Included)	73 lbs
Plug Location	Left Side
Cord Length	74”
Approx. Heating Area	400 sq ft
